Bench LCR/ESR Meter with Component Tester

Discontinued Model 889B

Discontinued: October 17, 2021 MSRP $1,545 / 3 Yr Warranty
    • 300kHz Bench LCR Meter
    • Model 891
    • A compact, precise, and versatile LCR meter capable of measuring inductors, capacitors, and resistors at DC or from 20 Hz to 300 kHz.

The B&K Precision Model 889B Synthesized LCR/ESR Meter with Component Tester is a high accuracy test instrument used for measuring inductors, capacitors and resistors with a basic accuracy of 0.1%. Also, with the built-in functions of DC/AC Voltage measurements and Diode/Audible Continuity checks, the Model 889B can not only help engineers and students to understand the characteristic of electronics components but also being an essential tool on any service bench.

Features:

  • Measurement parameters: ACV, DCV, Z, L, C, DCR, ESR, D, Q, and θ
  • LCR test conditions: 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz, 200 kHz , 1 Vrms, 0.25 Vrms, 0.05 Vrms, 1 VDC (DCR mode only)
  • Measures DCV to 600 V and ACV to 600 Vrms @ 40 ~ 1 kHz
  • Measures DCA to 2 A and ACA to 2 Arms @ 40 ~ 1 kHz
  • 0.1% basic accuracy
  • Diode and continuity measurements
  • Dual LCD display
  • BNC to Kelvin Clip probe included
  • USB (Virtual COM) Interface

Documentation

Software

Description Version Download
USB Driver v1.0 889B_USB_DRIVER.zip
  • Bench LCR Meter Test Fixture

    Model TL89F1

    Test fixture for convenient testing of axial and radial leaded type components.

    • Frequency: DC to 10MHz
    • DC Bias:+/- 40V peak max (AC+DC)
    • Operating Temperature: 0 to 40 degrees C
    • Terminal Connection: BNC to 4 terminal insertion slots (radial or axial)

    MSRP $103.00

  • Kelvin Clip Test Fixture

    Model TL89K1

    BNC to Kelvin clip test ficture for testing of leaded components.

    MSRP $60.00

  • Bench LCR Meter SMD Test Fixture

    Model TL89S1

    Test fixture for measuring small surface-mount devices (SMD)

    • Frequency: DC to 10MHz
    • DC Bias:+/- 40V peak max (AC+DC)
    • Operating Temperature: 0 to 40 degrees C
    • Terminal Connection: BNC, 4 terminal-pair
    • Dimensions(WxHxD): 5.125 x 2.37 x 3.31 inches (130 x 60.3 x 84mm) approximate
    • Weight: 0.67 lbs (0.305 kg) approximate



    TL89S1 Data Sheet and User Guide



    MSRP $399.00
