20 MHz DDS Sweep Function Generator with Arb Function

Discontinued Model 4045

Discontinued: October 3, 2012 MSRP $999 / 3 Yr Warranty

The model 4045 DDS Function Generator is a must have for anyone needing a low cost, full featured direct digital synthesis (DDS) function generator with arbitrary waveform capabilities. The 4045 has a menu-driven front panel interface that includes a large, easy-to-read graphical LCD display. Waveform parameter changes and data entry can be made using the rotary knob or via the built-in USB interfaces. The unit generates superb quality waveforms with high signal precision and stability. It provides sine & square wave outputs over the frequency range from 0.1 Hz to 20 MHz in one extended range (triangle/ramped wave outputs to 2MHz). Arbitrary waveforms can be edited from scratch or by modifying standard waveforms. A full range of triggering capabilities is available, including internal-external trigger source, gated and burst modes of operation.

  • 20MHz Frequency Range (sine & square only)
  • Sine, Square, Triangle & Arbitrary Waveforms
  • Clean, precise DDS waveform generation
  • Modulation in both AM & FM
  • Lin or Log Sweep Function
  • Adjustable Duty Cycle
  • Adjustable DC Offset
  • Bright Informative LCD
  • USB Interface

Documentation

Software

Description Version Download
USB Driver V1.00 4045_USB_driver.zip
Operating Software (Supports Windows 7; does not support 64-bit systems) V1.6 WaveX.ZIP
  • BNC Breakout to Alligator Clips

    BNC Breakout to Alligator Clips

    Model CC-21

    Standard BNC to Alligator clips test leads.

    • 50 ohm impedance
    • RG58C/u cable
    • 500Vrms voltage rating
    • 40" cable length

    MSRP $12.00

  • General Purpose Signal Interconnect Kit

    General Purpose Signal Interconnect Kit

    Model CC510

    Model CC510 General Purpose Function Generator and Oscilloscope Kit provides a range of BNC and N Type coaxial interconnection for basic function / arbitrary waveform generators use. All components feature standard BNC or N Type interfaces with 50 ohm impedance and gold plated center contacts to ensure accurate repeatable measurements. The kit is provided in a convenient foam lined storage case for easy selection and use. Features: BNC & N Type 50 ohm Connectors Gold plated center contacts Storage case Applications: Production Test Stations Service & Repair Facilities Educational Test Benches

    MSRP $195.00

  • Function, Pulse, and Arbitrary Waveform Generator Carrying Case

    Function, Pulse, and Arbitrary Waveform Generator Carrying Case

    Model LC 40
    • Made in the U.S.A.
    • Light weight, durable Cordura nylon
    • Protects your instruments from damage
    • Room to hold your test leads
    • Perfect size to accommodate bench a Function Generator, Pulse Generator or Arbitrary Waveform Generator
    • Approximate Internal Dimensions: 11 x 5.5 x 12" (279 x 140 x 305mm)

    MSRP $90.00

  • Function Generator Test Leads Set

    Function Generator Test Leads Set

    Model TLFG

    General purpose test probe set that includes BNC to BNC cables, BNC adapters and test clips.

    MSRP $91.00
